Specs & Key Features

  • Inputs
    •  4 universal Y/CV, Pb/C, Pr (composite, s−Video and component) 1 Vpp/75Ω on RCA connectors;
    • 2 UXGA on a 15−pin HD connector (VGA through UXGA);
    • 2 HDMI connectors;
    • 1 USB connector;
    • For each universal input there is a corresponding (unbalanced) audio stereo input (1V nom./25kΩ minimum) and digital stereo S/PDIF input (32kHz to 96kHz sample frequency/75Ω) on RCA connectors;
      For each UXGA input there is a corresponding (unbalanced) audio stereo input on a 3.5mm mini jack connector.
  • Outputs
    • 1 HDMI connector
    • 1 UXGA on a 15 pin VGA
    • 1 balanced stereo audio output on a 5-pin terminal block
    • 1 digital S/PDIF output on an RCA connector
  • Supports HDMI and HDCP
  • Weight: 7.2lbs

VP−728

The VP−728 is a 9−input scaler/switcher for analog and digital video, unbalanced stereo, and S/PDIF audio signals. It up− or down−scales any video signal: composite, s−Video (Y/C), component video (YUV), HDMI, computer graphics video and JPEG files to a selectable graphics or HDTV output resolution via identical HDMI or 15−pin HD outputs. It provides glitch−free switching between sources through FTB™ (fade−thru−black) switching technology.
