Specs & Key Features

  • Inputs
    • Standard SDI: 8 signal lines, BNC x 8 (SDI INPUT 1 to SDI INPUT 8)
    • Up-converter function for SDI INPUT 5 to SDI INPUT 8 connectors
    • Standard DVI-D: 1 signal line, DVI-D x 1
    • Optional: Up to 4x additional signal lines (IN A1, IN A2, IN B1, IN B2)
    • Up to 2 option boards can be installed in the 2 input / output slots
  • Outputs
    • Standard SDI: 5 signal lines, BNC x 6 (SDI OUTPUT 1 to SDI OUTPUT 5 x 1 line each, 2x distributed outputs for SDI OUTPUT 1 only)
    • Standard DVI-D: 1 signal line, DVI-D x 1
    • Optional: Up to 4x additional lines (OUT A1, OUT A2, OUT B1, OUT B2): PGM, PVW, AUX1 to AUX4, MV (MULTI_VIEW), CLN, KEYOUT and MEM PVW can be assigned to SDI OUTPUT 1 to SDI OUTPUT 5, DVI-D OUT, OUT A1, OUT A2, OUT B1 and OUT B2 CLN can be pre-selected from KEY or DSK using menu
    • Up to 2x option boards can be installed in the 2 input / output slots
  • Signal Format
    • SD: 480 / 59.94i, 576 / 50i
    • HD: 1080 / 59.94i, 1080 / 50i, 720 / 59.94p, 720 / 50p, 1080 / 24PsF, 1080 / 23.98PsF
  • Signal Processing
    • Y: PB: PR 4: 2: 2, 10 bit (8 bit for video memory),
    • RGB 4:4:4, 8 bit
  • Weight: 13.7lbs

Multi-Format Live Switcher.

The Panasonic AV-HS410 HD / SD Multi-Format Live Switcher is a video production switcher boasting high performance and functionality in a compact form factor. Its intuitive user interface is designed for live production, while its plug-in compatibility makes for simple expansion. Nine standard inputs, including eight SDI and one DVI, and six standard outputs, including five SDI and one DVI, are present on the unit. You can add an additional four inputs and four outputs (not included). The integrated 7.0" (17.8 cm) multi-mode color LCD monitor shows versatile menus, an image monitor, waveform / vectorscope and more.
